| TYPE | DESCRIPTION |
| Mfr | 3PEAK |
| Series | - |
| Package | Tape & Reel (TR) |
| Product Status | ACTIVE |
| Package / Case | 10-VFDFN Exposed Pad |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 125°C |
| On-State Resistance (Max) | 1.5Ohm |
| -3db Bandwidth | 100MHz |
| Supplier Device Package | 10-DFN (3x3) |
| Voltage - Supply, Single (V+) | 1.65V ~ 5.5V |
| Charge Injection | 20pC |
| Crosstalk | -120dB @ 1MHz |
| Switch Circuit | SPDT - Open/Closed |
| Multiplexer/Demultiplexer Circuit | 2:1 |
| Channel-to-Channel Matching (ΔRon) | 120mOhm |
| Switch Time (Ton, Toff) (Max) | 40ns, 15ns |
| Channel Capacitance (CS(off), CD(off)) | 12pF |
| Current - Leakage (IS(off)) (Max) | 100nA |
| Number of Circuits | 2 |
